Century 1.5HP Single Speed Motor 56Y( Reconditioned)

Name: Century 1.5HP Single Speed Motor 56Y( Reconditioned)
Brand: Century
SKU: C1556Y
Price: 169.99 USD
Availability: InStock

$169.99

In stock

Product Details

UPC: 663001376644

Brand: Century

1.5HP 230V 56Y ODP SQFL MOTOR (MGT-60-5113). All single speed pool motors require shaft seals that are sold separately.

Ambient Temperature	50 deg C
Bearing Type	Ball
Brand	Regal Beloit
Diameter	6-1/2 Inch
Duty Cycle	Continuous
Efficiency Group	Standard
Enclosure Design	Open Dripproof
Finish Color	Black
Flange Material	Aluminum
Flange Type	Square
Frame	56Y
Frequency Rating	60 Hz
Full Load Amps	10 A
HP	1.5
Insulation Class	B
Item	Pool and Spa Pump Motor
Motor Design	PSC
Motor Shaft Rotation	CCWPE
Motor Thermal Protection	Auto
Mounting Type	C-Face, No Base
Overall Length	13.40 Inch
Phase	1-Phase
RPM	3450
Series	Centurion®
Service Factor	1.50
Shaft Design	Threaded
Shaft Diameter	5/8 Inch
Shaft Length	7/16 Inch
Shaft Material	303 Stainless Steel
Standards Approvals	UL 1081 Approved, UL Recognized (E14663), CSA Certified (LR4642)
Sub-Brand	Century®
Thrust Horsepower	2.25
Type	Full-Rated, CX
Voltage Rating	230 V
