A.O. Smith 1.5HP Single Speed Motor 56J( Reconditioned)

Name: A.O. Smith 56J Motor - 1.5HP Pump Motor | The PBM Store
Brand: Century
SKU: AOS1556J
Price: 199.99 USD
Availability: InStock

Store / Single Speed Motors

$199.99

In stock

Product Details

UPC: 786674031792

Brand: Century

1.5HP 115/208-230V EE 56J ODP THREADED MOTOR (AOS-60-5065). All single speed pool motors require shaft seals that are sold separately.

REGAL BELOIT AMERICA INC
MPN: ST1152
Product Line : Motors, Residential
Ship Weight (lbs.) : 30.85
Shipping Dimensions : 19.00x10.00x9.00

Ambient Temperature	50 deg C
Bearing Type	Sealed Ball
Brand	Regal Beloit
Diameter	6-1/2 Inch
Duty Cycle	Continuous
Efficiency Group	High
Enclosure Design	Open Drip proof
Finish Color	Satin Black
Flange Material	Aluminum
Frame	56J
Frequency Rating	60 Hz
Full Load Amps	19.6/10.4-9.8 A
HP	1.5
Insulation Class	B
Item	Two-Compartment Pool Filter Motor
Motor Design	Capacitor Start/Run
Motor Shaft Rotation	CCWPE
Motor Thermal Protection	Auto
Mounting Type	C-Face
Number of Speed	1-Speed
Overall Length	12.63 Inch
Phase	1-Phase
RPM	3450
Service Factor	1.47
Shaft Design	Threaded
Shaft Diameter	5/8 Inch
Shaft Length	2-9/16 Inch
Shaft Material	303 Stainless Steel
Standards Approvals	UL 1081 Approved, UL Recognized (E25022), CSA Certified (LR43341)
Sub Brand	Century®
Thrust Horsepower	2.25
Type	Full-Rated, UAK
Voltage Rating	115/208-230 V
