A.O. Smith 1.5HP Single Speed Motor 48Y (Reconditioned)

Name: 1.5HP Pump Motor - Single Speed Motor | The PBM Store
Brand: A.O. Smith
SKU: AOS1548Y
Price: 189.99 USD
Availability: InStock

Store / Single Speed Motors

$189.99

In stock

Product Details

UPC: 786674031167

Brand: A.O. Smith

1.5HP 230V EE 48Y ODP SQFL MOTOR (AOS-60-5060). All single speed pool motors require shaft seals that are sold separately.

REGAL BELOIT AMERICA INC
MPN : SQ1152
Product Line : Motors, Residential
Ship Weight (lbs) : 29.25
Shipping Dimensions : 20.50x11.00x9.00

AmbientTemperature	50 deg C
Application	Many Sta-Rite®, Red Jacket, Pac Fab and American Products
Bearing Type	Sealed Ball
Brand	Regal Beloit
Diameter	5-5/8 Inch
Duty Cycle	Continuous
Efficiency Group	High
Enclosure Design	Open Dripproof
Finish Color	Satin Black
Flange Type	Square
Frame	48Y
Frequency Rating	60 Hz
Full Load Amps	10.4 A
HP	1.5
Insulation Class	B
Item	Two-Compartment Pool Filter Motor
Motor Design	Capacitor Start/Run
Motor Shaft Rotation	CCWPE
Motor Thermal Protection	Auto
Mounting Type	C-Face
Number of Speed	1-Speed
Overall Length	13.25 Inch
Phase	1-Phase
RPM	3450
Service Factor	1.47
Shaft Design	Threaded
Shaft Diameter	5/8 Inch
Shaft Material	303 Stainless Steel
Standards Approvals	UL 1081 Approved, UL Recognized (E25022), CSA Certified (LR43341)
Sub-Brand	Century®
Thrust Horsepower	2.21
Type	Full-Rated, UAK
Voltage Rating	230 V
